1.3.6.8. Elemento base laterale
2.7. Elemento base posteriore
4.5. Elemento base orizzontale
9. Fondo base
10 Piano fuoco
11. Arco bocca
13. Separatore sinistro
14. Separatore destro
15. Elemento frontale
16. 17.18.19. Volta focolare
20. Elemento posteriore focolare
21. Rivestimento posteriore
22.23. Rivestimento laterale
24.25. Pannello di copertura laterale
27. Pannello di copertura centrale
28. Canna fumaria
29. Comignolo
